Industrial Synthetic Diamond Micron Powder for Polishing Wire Drawing Dies

Brand: HNHONGXIANG Diamond Powder<br> Types: Diamond micron powder, diamond polishing powder, synthetic micron diamond dust, die polishing diamond powder; <br> Usage: For polishing wire drawing dies; <br> Features: Long working life; High purity; Great polishing effect. <br>

Brief Introduction

   Diamond Powder For Mold Die Polishing
      The diamond micron powder refers to the diamond powder with a particle size of 0.1~54μm. The diamond powder is made of high-quality diamond as raw material and processed through strict standardization processes such as shaping, grading, purification, and quality test, etc.
      Diamond powders are used for reconditioning and manufacturing of Natural diamond dies, PCD dies, MONO dies and Tungsten Carbide dies.


Product Size

Die Mould Polish Diamond Powder
Product Photo Type  For ND Dies  For Mono Dies For Pcd Dies For TC Dies
Polishing Powder     0-0.25
    0-0.5
0-1 0-1 0-1
0-2 0-2 0-2
0-2 0-2 1-2
Lapping Powder 2-4 2-4 2-4 2-4
3-6 3-6 3-6 3-6
4-8 4-8 4-8 4-8
8-15 8-15 8-15 8-15
Grinding Powder 10-20 10-20 10-20 10-20
    20-40 20-40
    40-60 40-60
Storage Recommendations:
1. Please store in a dry state at room temperature to avoid moisture;
2. It is recommended to buy bottles with good airtightness, or put some desiccant;
3. It is recommended that the fine diamond micro powder should be used within two months after opening;

Product Application

Drawing Dies Polishing Video https://www.youtube.com/watch?v=XiyMhmr6V2U

    synthetic diamond micron powder is closely linked to the repair and polishing of wire drawing dies and is the most
suitable repair and polishing product, including PCD wire drawing dies, natural wire drawing dies, single crystal
wire drawing dies, single crystal wire drawing dies and other dies;
  • Diamond Micron Powder For Pcd Dies
  • Polishing Drawing Tc Die Diamond Powder
  • Diamond Micron Powder For Pcd Wire Drawing Dies

ND Wire Drawing Dies Mono Wire Drawing Dies PCD Wire Drawng Dies TC Wire Drawing Dies

Production Process

Other Diamond Tools for Wire Drawing Dies:
Product Photo Product Name Attribute
Diamond Lapping Paste is used for cutting and polishing of tungsten carbide wire dies( TC dies ). (0-1; 2-4; 4-8; 10-20; 20-40; 50-60)
Diamond Suspension is uesd for quick cutting and polishing of TC dies. (0-1; 2-4; 3-6; 4-8; 8-15; 10-20; 20-40; 40-60;)

Electroplated Diamond Angle Pins are used for grinding tungsten carbide dies.

Size: 6mm;
Angle: 6°/8°/10°/12°/14°;
Mesh: 120#;
Length: 100mm
Other sizes can be customized.
